Scientific Highlights

Magnetic two-dimensional (2D) materials are promising building blocks for realizing ultra-compact spintronic devices with enhanced performance. Their study is also expected to open new perspectives on a more versatile modulation of magnetic properties, beyond what can be achieved in traditional three-dimensional (3D) magnetic thin films and superlattices. In particular, combining magnetic 2D materials with other 2D crystals such as graphene and transition metal dichalcogenides (TMDCs) to create van der Waals (vdW) heterostructures offers great potential to tailor magnetism via proximity-induced phenomena.

The stacking of different two-dimensional (2D) materials such as graphene and hexagonal boron nitride (h-BN) allows to realize novel 2D heterostructures with tailored properties for application in atomically thin optoelectronic, electronic, and sensing devices. To achieve a high-density, bottom-up integration of such heterostructures in future technologies, the synthesis of 2D layers on top of each other via van der Waals epitaxy (vdWE) is a promising alternative to flake exfoliation followed by mechanical transfer, which is problematic in terms of scaling and reproducibility. However, due to the weak bonding between 2D crystals, vdWE is sensitive to various surface defects, usually leading to uncontrolled nucleation and thus non-uniform growth of polycrystalline material. Hence, the control over nucleation location is one of the key challenges to achieve scalable and high-quality fabrication of 2D heterostructures.

Phase change materials (PCM) are compounds employed in non-volatile random-access memory and rewriteable optical storage media thanks to the rapid and reversible transformation between the amorphous and crystalline states. GeSbTe alloys are the most studied PCMs and consist of lamellae separated by van der Waals gaps in the ordered crystalline phase. Here we report a methodology for the study of the two-dimensional (2D) character of epitaxial GeSbTe by looking at the weak inter-lamellae interactions. Our unique approach is the use of molecular beam epitaxy for the controlled synthesis of ultrathin films combined with Raman spectroscopy for the investigation of the PCM properties. The shift of the vibrational modes in the low-frequency range results in a direct probe of the film thickness.

Semiconductor heterostructures are intrinsic to a wide range of modern-day electronic devices, such as computers, light-emitting devices and photodetectors. Knowledge of chemical interfacial profiles in these complex structures is critical to the task of optimizing the device performance. Here, we report on an innovative methodology that enables reliable interface structure analysis of non-common-atom heterovalent interfaces on all relevant length scales from hundred-nm to atomic resolution.

The chamber geometry of a system for molecular beam epitaxy (MBE) is known to affect technical aspects such as the macroscopic deposition homogeneity across a wafer. However, for the microscopic mechanisms governing the growth of thin films on a planar substrate, the chamber geometry does not play any role. In marked contrast, we show here that the luminescence efficiency of (In,Ga)As/GaAs shell quantum wells grown around GaAs nanowires changes by more than two orders of magnitude depending on the relative position of the As cell compared to the group-III cells.

A strong asset of bottom-up nanowires and related nanowire heterostructures is the enhanced surface strain relaxation that delays the onset of plastic relaxation. As a matter of fact, GaN nanowires essentially free of dislocations can be directly grown on technologically relevant substrates such as silicon or metals. Yet, in spite of their high structural perfection – on par with bulk GaN – the electron-hole recombination in these nanoscopic structures remains predominantly nonradiative, even at cryogenic temperature. Here, we provide first evidence that the efficient nonradiative channel does not take place at point defects located at the nanowire surface or in the bulk, but stems instead from field-ionization of the exciton in the surface electric field.

The monolithic integration of light emitters on Si remains an important technological challenge for the development of intra-chip optical connections, as well as inter-chip connections. In this context, GaAs nanowires grown on Si substrates offer great potential, but their effective use for Si photonics technologies requires operation in the Si transparent window, with special relevance of the telecommunication bands for potential data transfer applications. Here, we present a novel coaxial nanowire heterostructure to extend the emission range of GaAs-based nanowire devices into the telecommunication O band.

Electron spins are attractive qubits for the implementation of quantum functionalities in semiconductor devices. In this context, the spin transistor proposed by Datta and Das [Datta and Das, Appl. Phys. Lett. 56, 665, (1990)] has been a guiding concept towards the implementation of spin-based functionalities in III-V semiconductor structures. The acoustically driven flying spin gates enable a high degree of dynamic spin control as well as on-chip spin transfer over several tens of micrometers by simply changing the amplitude of the carrier acoustic wave. The approach is compatible with planar technology and also offers a convenient interface for the interconversion between electron spins and polarized phonons for long-distance quantum information transfer.
